Pressure Transducer (PT10)
Pressure Transducer (PT10)
The iC Pressure PT10 is made from stainless steel with a ceramic sensor making it a very versatile sensor for a range of applications including,
- Irrigation control
- Pump systems
- Filter systems
- Process water
- Raw water
- Various gauging ranges available
ENQUIRE
Resources
Company Policies
Manuals
Data Sheets
iC Pressure Sensors Datasheet
Installation Guides
Technical/Support Notes
Software
Design Tools
Product Drawings
Case Studies
Brochures
Presentations
Specs
Model Data: iC Pressure PT10
Input Voltage: 10-30 VDC
Output Signal: 4-20mA
Protection: IP65
Response Time: 10ms
Pressure Range: 0.5 – 50m (H2O)
Pressure Form: Gauge (G)
Gauging: Standard Models 0-600kPa, 0-1000kPa, 0-1600kPa, 0-3600kPa Other ranges on request, including negative ranges
Accuracy: +/- 0.5% F.S.
Operating Temp, Range Sensor, Dimensions: -40 to +85 c 35mm OD excluding cap, 100m long excluding nipple
Threaded Port: G1/4” x 20mm Long
